Ink Level Sensor
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
Rear cover (
page 51 "Rear Cover, Top Cover").
•
Top cover (
page 51 "Rear Cover, Top Cover").
•
Right cover (
page 53).
•
Maintenance unit (
page 64).
•
Right ink sump (
page 67).
•
Unlock the carriage (
page 62).
1. Push the carriage unit [A] to the center.
2. Remove the spring [A], and then remove the air release lever [B] ( x 2).
4. Replacement and Adjustment
102
