Ricoh Aficio SG 3100DN - Motors; Horizontal Motor

Motors
Horizontal Motor
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
Top cover (
page 51 "Rear Cover, Top Cover").
•
Rear cover (
page 51 "Rear Cover, Top Cover").
•
Canopy cover (
page 56).
•
Left cover (
page 55).
•
Right cover (
page 53).
•
Vertical encoder wheel (
page 69).
•
Fan, Fan bracket (
page 93 "Fan, Fan Bracket").
•
Unlock carriage unit (
page 62).
1. Push the carriage to the center.
Motors
89
