Covers
Cover Names
[1] Top Cover
[2] Canopy Cover
[3] Front Cover Brand Logo attached
[4] Operation Panel
[5] Right Front Cover Product Logo attached
[6] Output Tray
[7] Paper Cassette
[8] Rear Cover
[9] Duplex Unit
[10] Right Cover
[11] Left Cover
[12] Port Cover No screws, tabs only.
4. Replacement and Adjustment
50
