Top Cover Switch
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
Rear cover (
page 51 "Rear Cover, Top Cover").
•
Top cover (
page 51).
•
Right cover (
page 53).
•
Left cover (
page 55).
1.
The top cover switch is located on the CTL board.
2. The top cover switch ( x 1, x 2).
Sensors, Switches
109
