Input Check: Ink Cartridge Levels
5-804-016 INPUT CHK RES:Y Yellow Ink Cartridge
5-804-017 INPUT CHK RES:M Magenta Ink Cartridge
5-804-018 INPUT CHK RES:C Cyan Ink Cartridge
5-804-019 INPUT CHK RES:K Black Ink Cartridge
Use this SP to display the amount of ink that remains in each ink cartridge.
Units: %
Encoder Readings
5-804-020 INPUT CHK MENC Horizontal Encoder
Use this SP to display the current reading of the main scan encoder.
5-804-021 INPUT CHK SENC Vertical Encoder
Use this SP to display the current reading of the sub scan encoder.
Board Temperature Sensors
5-804-022 INPUT CHK DTEMP Drive Board Temperature Sensor
Displays the temperature reading of the temperature sensor in the DRV board
circuits.
Units: 0.1oC
5-804-023 INPUT CHK RCWS Right Ink Sump Set Status
This SP code checks the current status of the right ink sump. Displays "1" if set
correctly.
5-804-024 INPUT CHK RCWR Right Ink Sump Capacity
The SP code checks and displays the amount of space remaining in the right ink
sump.
5-804-025 INPUT CHK RCWC Right Ink Sump Count
This SP code checks and displays the software count for the right ink sump.
SP Mode Service Tables
59
