Ricoh Aficio SG 3100DN - 2 Nd Registration Sensor

2nd Registration Sensor
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
Rear cover (
page 51 "Rear Cover, Top Cover".
•
Top cover (
page 51 "Rear Cover, Top Cover").
•
Right cover (
page 53).
•
Left cover (
page 55).
1. The 2nd registration sensor is located on the pressure plate.
2.
The sensor cover (
x 2).
4. Replacement and Adjustment
106
