6. Slide the front cover [A] to the left to detach it.

7. Release the tabs and detach the operation panel board [A] ( x 5, x 1).

Re-assembly

Here are some points you should always check before re-attaching the covers.

Operation Panel

4. Replacement and Adjustment

58
