1. Make sure that the blue band of the FFC edge connector [A] is facing up
•
The blue band must be facing up when you reconnect the FFC to the operation FFC.
• If the FFC is twisted and connected with the blue band facing down, the printer will not
operate.
Front Cover
1. Align the tabs (three points) on the left bottom of the front cover with the machine's frame and slide
the cover to attach it.
Right Cover
1. Check that the harness and ink tube are secured.
•
Be sure to secure the harness with the tabs (at five points).
Common Procedures
59
