5. Separate the motor, motor bracket, and AC bracket ( x 2).
Re-installation:
When you attach the parts, attach the motor bracket afterward.
1. As shown, slide the right bottom part in, and then slide the left top part in.
2. After sliding the motor bracket in, slowly adjust the motor position to align the screw holes,
and then reassemble the parts.
Fan, Fan Bracket
Preparation:
• Duplex unit (J028/J029/J035) ( page 48).
• All covers ( page 50).
Motors
93
To Next Page
