Ricoh Aficio SG 3100DN - Control Boards

Control Boards
J027(ZICO) Controller
CPU SH2A
SoC ZICO
RAM SDRAM: 32MB
Program ROM On Board: 4MB
Font ROM None
EEPROM 4KB
Optional EEPROM slot None
PDL RPCS Raster
Connectivity
Host Interface(Std) USB 2.0 High Speed, 10BASE-T/100BASE-TX
Network Protocol TCP/IP
MIB Support Private:
Ricoh Original
Standard:
RFC1213(MIB-II)
RFC1514/RFC2970(Host Resource MIB)
RFC1759(Printer MIB)
RFC3412(MPD-MIB)
RFC3413(Target-MIB, Norification-MIB)
RCF3414(USM-MIB)
RFC3415(VACM-MIB)
RFC3584(COMMUNITY-MIB)
Printer Working Group Candidate Standard 5107.1-2005
(Printer Port Monitor MIB 1.0)
Specifications
