1st Registration Sensor
Preparation:
• Duplex unit (J028/J029/J035) ( page 48).
• Rear cover ( page 51 "Rear Cover, Top Cover").
• Top cover ( page 51 "Rear Cover, Top Cover").
• Right cover ( page 53).
• Left cover ( page 55).
• Canopy cover ( page 56).
• Unlock the carriage ( page 62).
1. The 1st registration sensor is located on the side of the carriage unit.
2.
Push the carriage to the center.
4. Replacement and Adjustment
104
