Temperature/Humidity Sensor
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
All covers (
page 50).
•
2nd registration sensor (
page 106).
•
Bypass drawer connector (
page 115).
•
Vertical encoder wheel (
page 69).
•
Transport belt (
page 97).
1. The temperature/humidity sensor ( x 1, x 4).
Trailing Edge Sensor
Preparation:
•
Duplex unit (J028/J029/J035) (
page 48).
•
All covers (
page 50).
•
2nd registration sensor (
page 106).
•
Bypass drawer connector (
page 115).
•
Vertical encoder wheel (
page 69).
•
Transport belt (
page 97).
1. The trailing edge sensor ( x 1, x 3).
4. Replacement and Adjustment
112
