2. Unhook the harness holder [A], and then lift it while sliding it to the right. Make sure to expose the

screw holes.

3. Open the AC inlet's bracket as shown ( x 3, x 1).

4. The vertical motor ( x 1, x 1).

4. Replacement and Adjustment

92
