Ricoh Aficio SG 3100DN User Manual

Branch
Sensor
Jammed paper location
2nd TE T-2 T-3
-06 --- On On ---
The paper is jammed in between the trailing edge sensor
and 2nd registration sensor. It is also jammed at the Tray
2 relay sensor.
If the paper was fed from Tray 2, its trailing edge is
located before the Tray 2 relay sensor (closer to Tray 2).
-07 On On On ---
The paper is located past the Tray 3 relay sensor (closer
to the output tray).
-08 --- --- --- On
The paper is jammed in between the Tray 3 relay sensor
and Tray 2 relay sensor.
If "JAM21-08" appears, the paper's trailing edge is
remaining in Tray 3.
-09 On --- --- On
1. The paper is jammed at the 2nd registration sensor. It
is not located at the trailing edge sensor or Tray 2
relay sensor.
1.
The paper is jammed in between the Tray 3 relay
sensor and Tray 2 relay sensor.
-10 --- On --- On
1. The paper is jammed in between the trailing edge
sensor and 2nd registration sensor. It is not located
at the Tray 2 relay sensor.
1. The paper is jammed in between the Tray 3 relay
sensor and Tray 2 relay sensor.
-11 On On --- ---
1. The paper is located past the Tray 2 relay sensor
(closer to the output tray).
1.
The paper is jammed in between the Tray 3 relay
sensor and Tray 2 relay sensor.
-12 --- --- On On
The paper is jammed in between the Tray 2 relay sensor
and trailing edge sensor.
If "JAM20-12" appears, the paper's trailing edge is
remaining in Tray 3.
6. Troubleshooting
240
