Use this SP code to adjust writing in the sub scan registration for normal paper
loaded in Tray 1. Do this setting when it is necessary to fine adjust the line feed
position.
[-128 to +127/FA/1/0.1mm]
1-001-006 REG:FD:GLOS:F (FA)
Adjust Sub Scan Registration (Glossy Paper)
1-001-007 REG:FD:GLOS:U
Use this SP code to adjust writing in the sub scan registration for glossy paper. Do
this setting when it is necessary to fine adjust the line feed position.
[-128 to +127/FA/1/0.1mm]
1-001-008 REG:FD2:NORM:F (FA)
Adjust Sub Scan Registration (Normal Paper:
Tray 2)
1-001-009 REG:FD2:NORM:U
Use this SP code to adjust writing in the sub scan registration for normal paper
loaded in Tray 2. Do this setting when it is necessary to fine adjust the line feed
position.
[-128 to +127/FA/1/0.1mm]
1-001-010 REG:FD3:NORM:F (FA)
Adjust Sub Scan Registration (Normal Paper:
Tray 3)
1-001-011 REG:FD3:NORM:U
Use this SP code to adjust writing in the sub scan registration for normal paper
loaded in Tray 3. Do this setting when it is necessary to fine adjust the line feed
position.
[-128 to +127/FA/1/0.1mm]
1-001-012 REG:FDM:NORM:F (FA)
Adjust Sub Scan Registration (Normal Paper:
Bypass Tray)
1-001-013 REG:FDM:NORM:U
Use this SP code to adjust writing in the sub scan registration for normal paper
loaded in Bypass Tray. Do this setting when it is necessary to fine adjust the line
feed position.
[-128 to +127/FA/1/0.1mm]
1-001-014 REG:FD2:GLOS:F (FA)
Adjust Sub Scan Registration (Glossy Paper:
Tray2)
1-001-015 REG:FD2:GLOS:U
2. Appendix: SP Mode Tables
40
