1-002-004 REG:TR2:NORM:F (FA)
Adjust Main Scan Registration (Normal Paper:
Tray 2)
1-002-005 REG:TR2:NORM:U
Use this SP code to adjust writing in the main scan direction for normal paper
loaded in Tray 2. Do this setting when registration does not match the image start
position on the user image adjustment menu.
[-128 to +127/FA/1/0.1mm]
1-002-006 REG:TR3:NORM:F (FA)
Adjust Main Scan Registration (Normal Paper:
Tray 3)
1-002-007 REG:TR3:NORM:U
Use this SP code to adjust writing in the main scan direction for normal paper
loaded in Tray 3. Do this setting when registration does not match the image start
position on the user image adjustment menu.
[-128 to +127/FA/1/0.1mm]
1-002-008 REG:MAN:NORM:F (FA)
Adjust Main Scan Registration (Normal Paper:
Bypass Tray)
1-002-009 REG:MAN:NORM:U
Use this SP code to adjust writing in the main scan direction for normal paper
loaded in Bypass Tray. Do this setting when registration does not match the image
start position on the user image adjustment menu.
[-128 to +127/FA/1/0.1mm]
1-002-010 REG:TR1:GROS:F (FA)
Adjust Main Scan Registration (Glossy Paper:
Tray 1)
1-002-011 REG:TR1:GROS:U
Use this SP code to adjust writing in the main scan direction for glossy paper
loaded in Tray 1. Do this setting when registration does not match the image start
position on the user image adjustment menu.
[-128 to +127/FA/1/0.1mm]
1-002-012 REG:TR2:GROS:F (FA)
Adjust Main Scan Registration (Glossy Paper:
Tray 2)
1-002-013 REG:TR2:GROS:U
Use this SP code to adjust writing in the main scan direction for glossy paper
loaded in Tray 2. Do this setting when registration does not match the image start
position on the user image adjustment menu.
[-128 to +127/FA/1/0.1mm]
2. Appendix: SP Mode Tables
42
