Ricoh Aficio SP 5200DN User Manual

5. Press the [ ] or [ ] key to select [Print Test Sheet], and then press the [OK] key.
6. Press the [ ] or [ ] key to select the tray you want to adjust, and then press the [OK] key.
7. Confirm the position of the image on the test sheet, and then adjust the registration value.
Use this sheet to confirm the current print position.
8. Press the [Escape] key until the screen returns to the [Registration] menu.
9. Press the [ ] or [ ] key to select [Adjustment], and then press the [OK] key.
10. Press
the [
] or [ ] key to select the parameter you want to adjust, and then press the [OK]
key.
8. Adjusting the Printer
166
8
