Ricoh Aficio SP 5200DN

11. Enter the value (mm), and then press the [OK] key.
Increase the value to shift the print area in the direction indicated by the " " symbol in the diagram
below. Decrease the value to shift the print area in the direction indicated by the " " symbol.
1
2
CEC241
: Print Area
: Paper Feed Direction
Pressing the [ ] or [ ] key adjusts the value up or down in 0.1 mm increments.
12. Press the [OK] key to return to the [Registration] menu.
13. Print the test sheet to confirm the adjustment result.
14. Press the [Menu] key to return to the initial screen.
Adjusting Printing Position
167
8
