• The port name that follows "WSD" uses random character strings. It cannot be changed freely.
• To
stop the installation, click [Cancel] before the installation is complete. When re-installing the WSD
Port, right-click the printer's icon in the [Network] window, and then click [Uninstall].
Windows 7, Windows Server 2008 R2 - WSD port
1. Close all applications except this manual.
2. On the [Start] menu, click [Computer].
3. Click [Network].
4. Right-click the icon of the printer model you want to use, and then click [Install].
Installation
begins automatically. If the "Device driver software was not successfully installed" message
appears, close the message and proceed to step 5.
5. On the [Start] menu, click [Devices and Printers].
6. Click [Add a printer].
7. Click [Add a local printer].
8. Select the [Use an existing port:] check box, and select the WSD port.
9. Click [Next].
10. Click [Have Disk...].
11. Insert the provided CD-ROM into the computer's CD-ROM drive.
If the [AutoPlay] window appears, click the [Close] button.
12. Click [Browse...], and then specify the location of the INF file.
If the CD-ROM drive is D, the source files of the printer driver are stored in the following locations:
• PCL 5e
D:\DRIVERS\PCL5E\XP_VISTA or x64\(language)\DISK1
• PCL 5c
D:\DRIVERS\PCL5C\XP_VISTA or x64\(language)\DISK1
• PCL 6
D:\DRIVERS\PCL6\XP_VISTA or x64\MUI\DISK1
• PostScript 3
D:\DRIVERS\PS\XP_VISTA or x64\MUI or (language)\DISK1
If the file path of the printer driver contains the word "MUI", the driver will be installed in the language
of the operating system.
2. Network Connection
20
