SP Mode Tables
SM Appendix 4-7 D096
Appendix:
SP Mode
Tables
2220
TD Sensor Output Value Display
2220 1
Displays:
Vt: the current TD sensor output value and
Vref: the target TD output value Vts (SP 2926) + correction for ID sensor
output.
The TD sensor output value changes every copy. If 1 > 2, toner is supplied to
the development unit.
2221
ID Sensor Error Analysis
2221 1 Vsg Displays the Vsg value.
2221 2 Vsp Displays the Vsp value.
2221 3 PWM Displays the PWM value.
2221 4 Vsdp Displays the Vsdp value.
2221 5 Vt Displays the Vt value.
2221 6 Vts Displays the Vts value.
2301*
Transfer Current Adjustment
2301 1
Normal paper
[–2 = –4 mA / –1 = –2 mA / 0 = 0 mA / 1 = 2 mA /
2 = +4 mA]
Adjusts the current applied to the transfer roller when feeding from a paper
tray. Use a high setting if the user normally feeds relatively thick paper (within
spec) from a paper tray (
Image Transfer Current Timing).
