SAM4s ER-900 Series Operator's & Programming Manual v.1.28 Integrated Payment Appendix • 233
Required ECR Programs
1. You must set EFT status for the port you are using. See “RS-232 Communication Option
Programs” on page 101. Set device function to “EFT Device” and set BAUD to “2400”.
2. See System Option Programming on page 137. Set address #39 to 0 for Normal Draft with
Normal Buffer Use. Add the value of 2 to your current value for a draft with a tip line. Set
address #37 to define where the MSR is connected-the of 2 (defaut value ) should be set
when the MSR is a the register.
3. See Print Option Programming on page 145. Set address #35 for the number of Datatran
receipt copies you wish to print (0-99).
4. See CHARGE 1-8 - Function Key Options on page 159. Set option N5 to reflect the type of
payment: Credit, Debit or Gift (check with your representative for availability of gift card
processing).
Local Transaction Report Key
A B C D E F G H I J K H I J K L M N O P Q R S T [U V WX Y Z AA BB]
Field Description Min Max Type
A Transaction Sequence Number 1 5 Numeric
B Transaction Status 1 1 Alphanumeric
C Network Transaction Code 1 3 Alphanumeric
D Credit Card Account Number 1 38 Alphanumeric
E Expiration Date 4 4 Numeric
F Card Reader Flag 1 1 Numeric
G Approval Code 1 16 Alphanumeric
H Reference Number 1 16 Alphanumeric
I Transaction Amount 3 11 Numeric
J Operator ID 1 10 Alphanumeric
K AMEX Category or Product Code 1 10 Alphanumeric
L Arrival Date 3 6 Numeric
M Departure Date 3 6 Numeric
N Gratuity Amount 3 11 Numeric
O Media Type 1 2 Numeric
P Special Program Code 1 1 Numeric
Q Transaction Date 3 6 Numeric
R Transaction Time 4 4 Numeric
S Authorization Source Code 1 1 Numeric
T Card Holder ID 1 1 Numeric
U PS2000 or MIC Payment Service Indicator 1 1 Alphanumeric
V PS2000 Transaction ID or 15 15 Alphanumeric
MIC Banknet Reference Number 9 9 Alphanumeric
MIC Banknet Authorization Date 4 4 Numeric
MIC POS Entry Mode 1 1 Alphanumeric
MIC Mag Stipe Error Code 1 1 Alphanumeric
W PS2000 Validation Code 4 4 Alphanumeric
X Authorization Response Code 2 2 Alphanumeric
Y PS2000 Authorization Currency Code or 3 3 Alphanumeric
MIC Entry Mode Change Indicator 1 1 Alphanumeric
