4 Operation and Configuration
141
SG112-ex Operator Manual
INTERFACE SELECT
Select the upload method.
• SD CARD: Upload data to an SD card.
• USB MEMORY: Upload data to a USB memory.
UPLOAD SELECT
Select the item to be uploaded.
• FIRMWARE: Upload “Firmware”.
• KANJI FONT: Upload “Kanji font” and “Kanji outline font”.
• CONFIG: Upload product configurations.
• FONT/LOGO: Upload font/logo data.
• STS5 LOG: Upload Status5 log.
• ALL: Upload all data.
READING. . . XX/XX (UPLOAD)
The product is reading the uploaded data.
The bar on the lower portion of the screen indicates the data reading
progress.
XX/XX shows the file number being read and total number of files.
After reading the data, it goes to the WRITING… screen.
WRITING. . . XX/XX (UPLOAD)
The product is writing the uploaded data.
The bar on the lower portion of the screen indicates the data writing
progress.
XX/XX shows the file number being written and total number of files.
