MRD 3187B - User Manual
Page 127 (245)
3. Use the and buttons to
select the column to edit and use
the and buttons to
change the IP address, then press
the button to save the
selection.
Note: A maximum of 64 IP addresses may be added to the list.
Edit/Remove an IP
Note: Existing IP addresses are shown before the “Add IP” option.
1. Use the and buttons to
move the cursor to the desired IP
address to edit, then press the
button.
2. Use the and buttons to
select either “Edit” or “Remove”,
then press the button.
Clear All
This option will clear all IP addresses in the filter list.
1. Use the and buttons to
move the cursor to “Clear All”, then
press the button.
2. Press the button one more
time to clear all the IP addresses in
the list.
Receive 2
This section allows the user to setup the receive function of the second receive
group.
1. Use the and buttons to move
the cursor to “Receive 1” then press
the button.
2. Use the and buttons to move
the cursor to “Receive:” then press the
button.
3. Use the and buttons to
“Enable” or “Disable” Receive 1, then
press the button to save the
selection.
MPEG/IP 1-4 2
►Receive:Enable
Phys Conn:Port 1
Ip:239.192.0.1
MPEG/IP 1-4
Timeout:0.5s
Receive 1
►Receive 2
MPEG/IP 1-4 1
239.192.20.3
Add IP
►Clear All
MPEG/IP 1-4 1 ←→
Filter Mode:Include
Edit Remove
Add IP
MPEG/IP 1-4 1
►239.192.20.3
Add IP
Clear All
MPEG/IP 1-4 1 ←→
Filter Mode:Include
000.000.000.000
Clear All
