MRD 3187B - User Manual
Page 129 (245)
Synchronized Source Setup
1. Use the and buttons to move
the cursor to “SSRC:” then press the
button.
2. Use the and buttons to
select “Enable” or “Disable”, then
press the button to save the
selection.
Synchronized Source Setup Filter
1. Use the and buttons to move
the cursor to “SSRC Filt:” then press
the button.
2. Use the and buttons to
select the column to edit and use the
and buttons to change the
SSRC Filter, then press the
button to save the selection.
Buffer
3. Use the and buttons to move the
cursor to “Buffer:” then press the
button.
4. Use the and buttons to select
the column to edit and use the and
buttons to change the Buffer (from
3999 kb to 100 kb), then press the
button to save the selection.
IGMP V3 Source Filter
1. Use the and buttons to move
the cursor to “IGMP V3 Src Filter”,
then press the button to access
the Edit screen.
Filter Mode
1. Use the and buttons to
move the cursor to “Filter Mode:”
then press the button.
2. Use the and buttons to
select either “Include” or “Exclude”,
then press the button to save
the selection.
MPEG/IP 1-4 2
►Filter Mode:Include
Add IP
Clear All
MPEG/IP 1-4 2
SSRC Filt:0x00000000
Buffer:0100kb
►IGMP V3 Src Filter
MPEG/IP 1-4 2 ←→
SSRC Filt:0x00000000
►Buffer:0100kb
IGMP V3 Src Filter
MPEG/IP 1-4 2 ←→
FEC:Disable
SSRC:Disable
►SSRC Filt:0x00000000
MPEG/IP 1-4 2
FEC:Disable
►SSRC:Disable
SSRC Filt:0x00000000
