MRD 3187B - User Manual
Page 130 (245)
Add IP
1. Use the and buttons to
move the cursor to “Add IP”, then
press the button.
2. Press the button again to add
an IP address to the list.
Note: Existing IP addresses are shown before the “Add IP” option.
3. Use the and buttons to
select the column to edit and use
the and buttons to
change the IP address, then press
the button to save the
selection.
Note: A maximum of 64 IP addresses may be added to the list.
Edit/Remove an IP
Note: Existing IP addresses are shown before the “Add IP” option.
1. Use the and buttons to
move the cursor to the desired IP
address to edit, then press the
button.
2. Use the and buttons to
select either “Edit” or “Remove”,
then press the button.
Clear All
This option will clear all IP addresses in the filter list.
1. Use the and buttons to
move the cursor to “Clear All”, then
press the button.
2. Press the button one more
time to clear all the IP addresses in
the list.
Reset Counters
This option will reset the counters on the status screen for the MPEG/IP card.
1. Use the and buttons to move the
cursor to “Reset Counters”, then press the
button.
2. Press the button again to reset the
counters.
MPEG/IP 1-3
Receive 1
Receive 2
►Reset Counters
MPEG/IP 1-4 2
239.192.20.3
Add IP
►Clear All
MPEG/IP 1-4 2 ←→
Filter Mode:Include
Edit Remove
Add IP
MPEG/IP 1-4 2
►239.192.20.3
Add IP
Clear All
MPEG/IP 1-4 2 ←→
Filter Mode:Include
000.000.000.000
Clear All
MPEG/IP 1-4 2
Filter Mode:Include
►Add IP
Clear All
