MRD 3187B - User Manual
Page 159 (245)
Audio 1 Type
1. Use the and buttons to
move the cursor to “Audio1 Typ:”
then press the button.
2. Use the and buttons to
select the audio type (“Dolby AC3”,
“Dolby E”, “MPEG 1”, ”MPEG 2”)
on the PID chosen above, then
press the button.
Audio 2 PID
1. Use the and buttons to
move the cursor to “Aud 2 PID:”
then press the button.
2. Use the and buttons to
select the column to edit, then use
the and buttons to select
the desired Audio PID in the
stream, then press the button
to save the PID.
Audio 2 Type
1. Use the and buttons to
move the cursor to “Audio2 Typ:”
then press the button.
2. Use the and buttons to
select the audio type (“Dolby AC3”,
“Dolby E”, “MPEG 1”, ”MPEG 2”)
on the PID chosen above, then
press the button.
Audio 3 PID
3. Use the and buttons to
move the cursor to “Aud 3 PID:”
then press the button.
4. Use the and buttons to
select the column to edit, then use
the and buttons to select
the desired Audio PID in the
stream, then press the button
to save the PID.
Serv Setup ←→
Audio2 Typ:Dolby AC3
►Aud 3 PID:0x0000
Audio3 Typ:Dolby AC3
Serv Setup
Audio1 Typ:Dolby AC3
Aud 2 PID:0x0024
►Audio2 Typ:Dolby AC3
Serv Setup ←→
Audio1 Typ:Dolby AC3
►Aud 2 PID:0x0000
Audio2 Typ:Dolby AC3
Serv Setup
Video Type:MPEG 2
Aud 1 PID:0x0022
►Audio1 Typ:Dolby AC3
