MRD 3187B - User Manual
Page 41 (245)
Overlay (Service)
Note: This option only displays the Service
Info.
Overlay (Subtitle)
This overlays the DVB Subtitles. The subtitle is selected by choosing the
language to display. Only the available languages that are present can be
selected. When an input without DVB Subtitles is used, no language can be
selected.
Note: This menu changes depending on which overlay is set in “Overlay”.
1. Use the and buttons to move
the cursor to “Lang:” then press the
button.
2. Use the and buttons to select
the language from those that are
present, then press the button to
save the selection.
Small Format Display
To setup the MRD 3187B to output a “Small Format Display”, use the following
steps:
1. Use the and buttons to move the
cursor to “Small Format Disp”, then press
the button.
2. Press the button again to change the
settings.
Format
This output format is used whenever a small format (less than 720x480 or
720x567) is received. The small format video is placed in the output format
specified here in the position defined by the “SFD Location” setting.
1. While the cursor is on “Output Format:”
press the button to change the
display format.
2. Use the and buttons to
change from any of the format settings.
3. Press the button to save the
settings.
720x480i
4x3
29.97
720x480i
16x9
29.97
720x576i
16x9
25.00
720x576i
4x3
25.00
SFD 1-1
►Format:720x480i
4x3 29.97
SFD Location:Top-Lt
SD Video 1-1
SDI VANC Assignment
Overlay
►Small Format Disp
Overlay 1
Type:Subtitle
►Lang:------
Overlay 1
Type:Service
►Overlay:Service Info
