Horizontal
1. Use the and buttons to move
the cursor to “Horiz:” then press the
button.
2. Use the and buttons to select
the column to edit and use the
and buttons to change the
number of pixels, then press the
button to save the selection.
Note: The maximum amount of offset is determined by the format of the video
set.
Color Reference
Note: The Color Reference is only available when the Genlock reference is SD.
1. Use the and buttons to move
the cursor to “Color ref:” then press the
button.
2. Use the and buttons to select
the column to edit and use the
and buttons to change the
number of degrees (-180 – +180), then
press the button to save the
selection.
Small Format Display
To setup the MRD 3187B to output a “Small Format Display”, use the following
steps:
1. Use the and buttons to move the
cursor to “Small Format Disp”, then press
the button.
2. Press the button again to change the
settings.
Format
1. While the cursor is on “Format:” press
the button to change the display
format.
2. Use the and buttons to
change from any of the format
settings.
3. Press the button to save the
settings.
720x480i
16x9
29.97
1280x720p
16x9
59.94
720x480i
4x3
29.97
1280x720p
16x9
60.00
720x576i
16x9
25.00
1920x1080i
16x9
25.00
720x576i
4x3
25.00
1920x1080i
16x9
29.97
1280x720p
16x9
50.00
1920x1080i
16x9
30.00
SFD 1-1
►Format:1920x1080i
16x9 29.97
SFD Location:Top-Lt
Anlg Video 1-1
Overlay
Genlock Offset
►Small Format Disp
Genlock Offset
Vert:-125 lines
Horiz:-0177 pixels
►Color Ref:-100
Genlock Offset
Vert:-125 lines
►Horiz:-0177 pixels
Color Ref:-100
