MRD 3187B - User Manual
Page 67 (245)
Ancillary Data Packets
This controls the embedding to the Ancillary Data Packets (ADP) into the
VANC of the SDI output.
1. Use the and buttons to
move the cursor to the desired
type of Ancillary Data Packet
(“EIA-608CC”, “EIA-708CC”, “TTX
S2031M”, “Source ID”, or “SCTE
127”, “AFD”), then press the
button.
2. Use the and buttons to
choose “Enabled” or “Disabled”,
then press the button to save
the selection.
3. Use the and buttons to
select “Line:” for the ADP and
press the button.
4. Use the and buttons to
change the line number (4 – 15) in
which the ancillary data will be
located.
Note: Repeat steps 1-4 above to change EIA-708CC, TTX S2031M, Source
ID, SCTE 127 and AFD.
SD Settings
1. Use the and buttons to move the
cursor to “SD Settings”, then press the
button to display the Status screen
for the SD video output settings.
2. Press the button again to display the
Edit screen for the SD video output
settings.
Display Mode
1. Use the and buttons to move
the cursor to “Disp Mode:” then press
the button.
2. Use the and buttons to
select the desired output size
(“Letterbox”, “Anamorph”, or
“Cropped”), then press the
button to save the selection.
SD Settings 2-1
►Disp Mode:Cropped
Video Loss Mode:
Display Raster
SDI Anlg Vid 2-1
Video
HD Settings
►SD Settings
SDI VANC 2-1
ADP
EIA-608CC:Disabled
► Line: 9
SDI VANC 2-1
ADP
► EIA-608CC:Disabled
Line:9
