description of the error will be shown in the “Active Errors” menu under the
button, and an entry will be logged in the event log. The video will restore but will not
be Genlocked until the Genlock signal is restored.
When the “Genlock Reference” is set to an SD source of NTSC or PAL, the “Genlock
Offset” includes a “Color Ref” setting.
Note: This mode is only available if the unit is equipped with an 8731A/8734 decoder
as well as the 8708 video output card.
1. Use the and buttons to move the
cursor to “Genlock Offset,” then press the
button.
Vertical
1. Use the and buttons to move
the cursor to “Vert:” then press the
button.
2. Use the and buttons to select
the column to edit and use the
and buttons to change the
number of lines, then press the
button to save the selection.
Note: The maximum amount of offset is determined by the format of the video
set.
Horizontal
1. Use the and buttons to move
the cursor to “Horiz:” then press the
button.
2. Use the and buttons to select
the column to edit and use the
and buttons to change the
number of pixels, then press the
button to save the selection.
Note: The maximum amount of offset is determined by the format of the video
set.
Color Reference
Note: The Color Reference is only available when the Genlock reference is SD.
Genlock Offset
Vert:-125 lines
►Horiz:-0177 pixels
Color Ref:-100
Genlock Offset
►Vert:-125 lines
Horiz:-0177 pixels
Color Ref:-100
SDI Anlg Vid 2-1
►Genlock Offset
Overlay
Small Format Disp
To Next Page
