MRD 3187B - User Manual
Page 72 (245)
1. Use the and buttons to move
the cursor to “Color ref:” then press the
button.
2. Use the and buttons to select
the column to edit and use the
and buttons to change the
number of degrees (-180 – +180), then
press the button to save the
selection.
Overlay Settings
Overlays provide an easy way to help troubleshoot problems, monitor stream
characteristics, or decode closed captioning.
CAUTION: All overlays will appear on the downstream video.
1. Use the and buttons to move the
cursor to “Overlay”, then press the
button.
Type of Overlay
3. Use the and buttons to move
the cursor to “Type:” then press the
button.
4. Use the and buttons to
select which overlay to display (“Off”,
“Closed Caption”, “Service”, “Table”,
“Subtitle”) then press the button
to save the selection.
Note: The “1” in “Overlay 1” refers to the RDS.
Overlay (Closed Caption)
Note: This menu changes depending on which overlay is set in “Type of Overlay”
above.
3. Use the and buttons to move
the cursor to “Overlay:” then press the
button.
4. Use the and buttons to
select the appropriate type of overlay
(“NTSC” or “DTVCC”), then press the
button to save the selection.
Overlay 1
Type:Closed Caption
►Overlay:NTSC
NTSC Srvc:1
Overlay 1
►Type:Closed Caption
Overlay:NTSC
NTSC Srvc:1
SDI Anlg Vid 2-1
Genlock Offset
►Overlay
Small Format Disp
Genlock Offset
Vert:-125 lines
Horiz:-0177 pixels
►Color Ref:-100
