MRD 3187B - User Manual
Page 73 (245)
NTSC Closed Captions
Note: This option will only be available if the TYPE of overlay is set to,
“Closed Caption” and the “Overlay” is set to “NTSC.”
3. Use the and buttons to
move the cursor to “NTSC Srvc:”
then press the button.
4. Use the and buttons to
select the desired number of
closed caption to view (1-4), then
press the button to save the
selection.
DTVCC Closed Captions
Note: This option will only be available if the TYPE of overlay is set to,
“Closed Caption” and the “Overlay” is set to “DTVCC.”
3. Use the and buttons to
move the cursor to “DTVCC Srvc:”
then press the button.
4. Use the and buttons to
select the desired number of
closed caption to view (1-7), then
press the button to save the
selection.
Overlay (Table)
Note: This menu changes depending on which overlay is set in “Overlay”.
3. Use the and buttons to move
the cursor to “Overlay:” then press the
button.
4. Use the and buttons to
select the appropriate type of overlay
(“PSI PAT”, “PSI PMT”, “ATSC MGT”,
“ATSC STT”, “ATSC TVCT”, “ATSC
EIT”, “ATSC EPG”), then press the
button to save the selection.
Screen Interaction
This mode allows the user to page through the on-screen PSI/ATSC tables.
Note: This option will only be available if the type of overlay is set to, “Table.”
3. Use the and buttons to
move the cursor to “Screen
Interaction”, then press the
button.
4. While this mode is enabled, the
, , , and buttons
will control the on-screen
PSI/ATSC tables. To exit the,
“Screen Interaction” mode press
the button.
Overlay 1
Type: Table
Overlay: PSI PMT
►Screen Interaction
Overlay 1
Type: Table
►Overlay: PSI PAT
Screen Interaction
Overlay 1
Type:Closed Caption
Overlay:DTVCC
►DTVCC Srvc:1
Overlay 1
Type:Closed Caption
Overlay:NTSC
►NTSC Srvc:1
