MRD 3187B - User Manual
Page 74 (245)
Coordinated Universal Time Offset
3. Use the and buttons to
move the cursor to “Utc Offset:”
then press the button.
4. Use the and buttons to
change to the appropriate offset,
then press the button to save
the selection.
Note: The UTC values and their offsets are listed in Appendix E.
Overlay (Service)
Note: This option only displays the Service
Info.
Overlay (Subtitle)
This overlays the DVB Subtitles. The subtitle is selected by choosing the
language to display. Only the available languages that are present can be
selected. When an input without DVB Subtitles is used, no language can be
selected.
Note: This menu changes depending on which overlay is set in “Overlay”.
3. Use the and buttons to move
the cursor to “Lang:” then press the
button.
4. Use the and buttons to
select the language from those that
are present, then press the
button to save the selection.
Small Format Display
To setup the MRD 3187B to output a “Small Format Display”, use the following
steps:
1. Use the and buttons to move the
cursor to “Small Format Disp”, then press
the button.
2. Press the button again to change the
settings.
Format
This output format is used whenever a small format (less than 720x480 or
720x567) is received. The small format video is placed in the output format
specified here in the position defined by the “SFD Location” setting.
SDI Anlg Vid 2-1
Genlock Offset
Overlay
►Small Format Disp
Overlay 1
Type:Subtitle
►Lang:------
Overlay 1
Type:Service
►Overlay:Service Info
Overlay 1
Screen Interaction
►Utc Offset:-06:00
Central
