1.3 Order Information
The ordering options shown below include all drive models in the CDHD2S product line. To
inquire about product availability, please contact Servotronix.
Table 1-2 CDHD2S Ordering Plan
CDHD2S
–
012
4D
EC2
–
RO
000
CDHD2SServo Drive – HD Series
Power specifications
1D5
003
4D5
006
012
024
030
120/240 VAC
1.5 4.5
3 9
4.5 18
6 18
400 / 480 VAC
Cont.
[A rms]
Peak
[A rms]
12
24
24
72
30
90
Input power supply
2A
MV input power supply
Single phase input 120 L-L VAC +10% -15%
50/60 Hz
Single phase input 240 L-L VAC +10% -15%
50/60 Hz
Three phase input 120-240 L-L VAC +10% -
15% 50/60 Hz
4D
HV input power supply
•Three phase input 400 L-L VAC +10% -15% 50/60
Hz
•Three phase input 480 L-L VAC +10% -15% 50/60
Hz
24VDC control board power supply
Communication interface
Communication
interface
EC2
EtherCAT, USB.
2
PN2
PROFINET, USB.
2
x = 1: One analog input, 16 bit
x = 2: Two analog inputs, 14 bit each
* Standard
configuration
Motor type
[blank]
Rotary servo motors, linear motors and DD motors
RO
RO models are only suitable for rotary motors
Special options
[blank]
Standard
Note: EC version only has 12A, 24A and 30A 380V HV models.
