11. CDHD2S Accessories
11.1 Mating Connector Kit
Table 11-1
Description
Servotronix part number
CDHD2S (medium-voltage) power supply mating 1.5A, 3A, AC voltage
120/240V, spring
KIT-2A-PWSPR-00
CDHD2S (medium-voltage) power supply mating 4.5A, 6A, AC voltage
120/240V, spring
KIT-2B-PWSPR-00
CDHD2S (medium-voltage) power supply mating 8A, 10A, 13A, AC voltage
120/240V, crimped
KIT-2C-POWER-00
CDHD2S (medium-voltage) power supply mating 20A, 24A, AC voltage
120/240V, spring
KIT-2D-PWSPR-00
CDHD2S (low-voltage) power supply mating 3A, 6A, 12A, 15A, AC voltage
20/90V
KIT-1D-POWER-00
CDHD2SC2 - controller interface MDR36 pin
KIT-C2MDR36000
CDHD2SC3 – machine interface MDR20 pin
KIT-C3MDR20000
CDHD2SC4 – feedback MDR26 pin
KIT-C4MDR26000
CDHD2SSTO connector
KIT-00P1000-00
11.2 Cable
Table 11-2 C1 - USB2.0A to Mini-B cable
Note: It is strongly recommended that you use the USB cable provided by Servotronix, which
has been tested and proved to be reliable..
Item
Specification
Servotronix part number
USB2.0A to Mini-B cable
CBLr0000USBA-00
Shielding
85% copper braided wire shield
coverage
Twisted pair cables
Required
Maximum length
3m
Wire gauge
20–28AWG
EMI filtering
2 ferrite cores, located near each
connector
Table 11-3 C2 - controller interface cable
Item
Specification
Servotronix part number
USB2.0A to Mini-B cable
CBLr0000USBA-00
Shielding
85% copper braided wire shield
coverage
Twisted pair cables
Required
Maximum length
3m
