Servotronix CDHD2S - Power Board Connection

驱动器设置
—85—
Table 4-36 Gantry daisy chain C8 wiring
Gantry master (Y1)
Drive
Gantry differential
(Y2) drive
Twisted pair cables
Signal declarations
7
7
Twisted pair cables
Serial data Tx+
8
8
Serial data Tx-
9
9
Twisted pair cables
Serial data Rx+
10
10
Serial data Rx-
Table 4-37 Gantry daisy chain C3 wiring
Gantry master (Y1)
Drive
Gantry differential
(Y2) drive
Twisted pair cables
Signal declarations
1
1
Twisted pair cables
Serial data Tx+
11
11
Serial data Tx-
2
2
Twisted pair cables
Serial data Rx+
12
12
Serial data Rx-
4.10 Power Board Connection
The power board interface varies with the specific CDHD2S model.
For power board, please refer to the power board pin assignment diagram.
Ensure that the main voltage rating meets the drive requirements. Applying an
incorrect voltage may cause the drive to malfunction.
Do not turn on the power supply until all hardware connections are completed.
