Table 4-4 Connector for feedback C4
Interface
Manufacturer
Item
Manufacturer
part number
Servotronix
part number
C4
3M
Welding plug connector
10126-3000PE
CONr00000026-31
3M
Welding plug shell
10326-52F0-008
HODr00000026-00
Table 4-5 Connector for fieldbus communication (EtherCAT/CAN) C5/C6
Interfac
e
Manufacturer
Item
Manufacturer
part number
Servotronix
part number
C5/C6
Molex
Connector
44915-0011
Table 4-6 Connector for RS232 serial communication C7
Interfac
e
Manufacturer
Item
Manufacturer
part number
Servotronix
part number
C7
AIM-Cambridge
Connector
32-5964UL
Table 4-7 Connector for RS232 serial communication C8
Interfac
e
Manufacturer
Item
Manufacturer
part number
Servotronix
part number
C8
TE
Connector
1658527-3
CONr00000010-67
4.4.4 Connector - power board
Note:
All connectors for power board are provided with the drive.
Table 4-8 Connector for CDHD2S-012 (high-voltage)
Interfa
ce
Function
Manufacturer
part number
Servotronix
part number
P1
STO
Crimp connection 15EDGKNM-3.5-
04P-14-1022Z (H)
Wire diameter: 16-28AWG
11201707001435
P2
24V logic power input
Crimp connection 15EDGKNM-3.5-
02P-14-1000A(H)
Wire diameter: 16-28AWG
11201707001436
P3
AC power input and
regenerative resistor
interface
Housing: SPC5/6-STCL-
7,62(1718520)
Wire diameter: 12-14AWG
CONr00000006-78 or
11201707000306
P4
Motor brake
Housing: SPC5/2-STCL-
7,62(1718481)
Wire diameter: 14-17AWG
CONr10000002-16 or
11201707000304
P5
Motor phase line
interface
Housing: SPC5/3-STCL-
7,62(1718494)
Wire diameter: 12-14AWG
CONr10000003-21 or
11201707000305
Table 4-9 Connector for CDHD2S-024 (high-voltage)/CDHD2S-030 (high-voltage)
