11.5 Regenerative resistor
The resistance value (ohms, W) is defined by the CDHD2S servo drive. The required power is
defined by the application. Therefore, each drive has multiple regenerative resistor options.
The manufacturer and part number of regenerative resistor recommended by CDHD2S are
listed in the following table.
Please refer to the Regeneration.
Table 11-13 Recommended regenerative resistors for CDHD2S medium-voltage models
CDHD2S-012
CDHD2S-024
CDHD2S-030
Power(W)
Minimum resistance 22Ω
Minimum resistance 12Ω
Minimum resistance 12Ω
300
CDHD2S built-in regenerative
resistor (P3)
CDHD2S built-in
regenerative resistor (P3)
CDHD2S built-in
regenerative resistor (P3)
600
ISOTEKULV600N33KFL500
Tobedefined.
Tobedefined.
1000
ISOTEKULV1000N33KFL500
Tobedefined.
Tobedefined.
2000
ISOTEKULM2000N33K
Tobedefined.
Tobedefined.
3000
FRIZLENFGFKU3100602-33
Tobedefined.
Tobedefined.
4000
FRIZLENFGFKU3100802-33
Tobedefined.
Tobedefined.
