For other models, no additional tools are required.
4.4.2 Cables and crimping
Please refer to the Cables section for details of the various cables required by the CDHD2S
system.
Before crimping, strip 2mm off the end of the wire, as shown in Figure 4-1.
Figure 4-1 Wire insertion into crimp pin
4.4.3 Connector - control board
For more information about cables, Please refer to the Cables section.
Table 4-2 Connector for controller interface C2
