Clear all blocking faults.
Return to the list of faults blocked by the drive.
Return to the content of the fault buffer.
Disable drive|Enable drive
Indicate whether the drive is ready to be enabled.
Indicate the external hardware enabling input status.
Return to the detailed status message of the drive.
10.3 Warning, error and fault messages
The following table shows the faults, warnings and error codes that may be displayed when
operating in terminal mode.
All faults as well as many warnings are also displayed via the drive digital display. Certain
conditions generate only on-screen warning messages.
10.3.1 Warning messages
CDHD2S drive warnings are reported in object 2011h.
Table 10-2 Warning codes and messages
Warning message (click description for more information)
Motor foldback warning Error!Referencesourcenotfound.
Power stage over-temperature
Control board over-temperature
Require phase find
The phase difference is required to initialize the commutation
angle.
PLL not synchronized
The phase locked loop (PPL) is not yet synchronized
(SYNCSOURCE>0).
Hardware positive limit switch open circuit
Hardware negative limit switch open circuit
Hardware positive and negative limit switches open circuit
Software forward limit switch trip
Software negative limit switch trip
Software limit switch trip
