Servotronix CDHD2S - Host System

驱动器设置
—37—
Interfa
ce
Function
Manufacturer
part number
Servotronix
part number
P1
STO
Crimp connection 15EDGKNM-3.5-
04P-14-1022Z (H)
Wire diameter: 16-28AWG
11201707001435
P2
STO2
Crimp connection 15EDGKNM-3.5-
04P-14-1022Z (H)
Wire diameter: 16-28AWG
11201707001435
P3
24V logic power input
Crimp connection 15EDGKNM-3.5-
02P-14-1000A(H)
Wire diameter: 16-28AWG
11201707001436
P4
Motor brake
Housing: SPC5/2-STCL-
7,62(1718481)
Wire diameter: 14-17AWG
CONr10000002-16 or
11201707000304
P5
AC power input and
regenerative resistor
interface
Housing: SPC5/6-STCL-
7,62(1718520)
Wire diameter: 12-14AWG
CONr00000006-78 or
11201707000306
P6
Motor phase line
interface
Housing: SPC5/3-STCL-
7,62(1718494)
Wire diameter: 12-14AWG
CONr10000003-21 or
11201707000305
4.4.5 Host system
The following computer systems and software are required:
⚫ 2GHzCPU
⚫ 1GBRAM
⚫ 1000MB of free hard drive space (after installing .net4)
⚫ Communication interface to the drive; one of the following:
◼ USB port
◼ USB port and USB-to-RS232 adapter (with ferrite beads)
◼ RS232 port
⚫ Operating system: Windows7, Windows8, Windows10, 32-bit or 64-bit.
⚫ For ServoStudio2, the recommended screen resolution is 1280x800; the
minimum resolution is 1024x800.
⚫ It is recommended to set your Windows monitor to small - 100% (default).
⚫ Net4 (please refer to the .NET Framework System Requirements for details).
If .NET4 is not installed on your computer, ServoStudio2 will guide you through
the installation but will not install it automatically.
⚫ ServoStudio2, a graphical software interface for configuring and testing the
drive. Download from the Servotronix website or contact technical support.
Please refer to Software Installation in the ServoStudio2 manual.
Note:
ServoStudio2 provides compatibility with CDHD2S firmware version 2.0 and
above.
Install ServoStudio2
1. Download the ServoStudio2 software installation file from the Servotronix website or contact
technical support.
