Troubleshooting
—257
—
Warning#
Number
Error message
Digital
display
Error code
ERR374
Error correction enabling requirements are not allowed to
be modified.
30cLv
08000000h
10.3.3 Fault messages
Table 10-4 Fault codes and messages
Fault#
Number
Fault message
(Click the description for more information)
Emergency (fault)
Error code
FLT1
Drive locking
8180h
FLT2
Parameter memory checksum failed
5585h
FLT3
Overcurrent
2214h
FLT4
STO fault
3181h
FLT5
FPGA configuration failed
6581h
FLT6
Control EEPROM fault
5581h
FLT7
Power supply EEPROM fault
5530h
FLT8
Vbus measurement circuit failed
3182h
FLT9
Overvoltage
3110h
FLT10
Power stage over-temperature
4310h
FLT11
Undervoltage
3120h
FLT12
Not configured
6381h
FLT13
Writing to flash memory failed
5586h
FLT14
Exceeding the velocity limit
8481h
FLT15
Encoder simulation frequency is too high
7387h
FLT16
Drive foldback
2311h
FLT17
Motor foldback
2310h
FLT18
A/B disconnection
7383h
FLT19
Invalid Hall
7384h
FLT20
Index disconnected
7111h
FLT21
Sine feedback communication failed
738Eh
FLT22
A/B out of range
738Fh
FLT23
Motor over-temperature
4410h
FLT24
Sine encoder quadrature fault
7391h
FLT25
Sine/cosine calibration is invalid
7392h
FLT26
Feedback 5V overcurrent
7393h
FLT27
Secondary feedback index disconnected
7180h
FLT28
Secondary feedback A/B line disconnected
7181h
