CDHD2S Accessories
—264
—
Wire gauge
20–28AWG
EMI filtering
2 ferrite cores, located near each
connector
Table 11-4 C3 - machine interface cable
Item
Specification
Servotronix part number
C2 fly wire
1 meter fly wire
2 meter fly wire
3 meter fly wire
5 meter fly wire
10 meter fly wire
CBL-MDR2-20-01
CBL-MDR2-20-02
CBL-MDR2-20-03
CBL-MDR2-20-05
CBL-MDR2-20-10
Table 11-5 C4 - feedback cable
Item
Specification
Servotronix part number
C2 fly wire
1 meter fly wire
2 meter fly wire
3 meter fly wire
5 meter fly wire
10 meter fly wire
CBL-MDR2-26-01
CBL-MDR2-26-02
CBL-MDR2-26-03
CBL-MDR2-26-05
CBL-MDR2-26-10
Table 11-6 C5|C6——RJ45 industrial Ethernet/EtherCATCat5e cable
Item
Specification
Servotronix
part number
RJ45CAT5E cable
Length: 0.5 meters
Length: 1 meters
Length: 2 meters
Length: 10 meters
CBLr00400100-00
CBLr00400180-00
CBLr00400110-00
CBLr00400140-00
Shielding
85% copper braided wire shield
coverage
Twisted pair cables
Required
Maximum length
10m
Wire gauge
26-27AWG
Table 11-7 C7 - RS232 cable
Item
Specification
Servotronix part number
RS232 cable
CBLrRS232AS0-01
Shielding
85% copper braided wire shield
coverage
Maximum length
10m
Wire gauge
24–28AWG
