Wiring - resolver
Table 4-35 Feedback wiring - resolver
Pin
Number
Twisted pair
cables
User motor pin
number
Signal declarations
6
Twisted pair
cables
Resolver sine+
19
Resolver sine -
7
Twisted pair
cables
Resolver cosine+
20
Resolver cosine -
8
Twisted pair
cables
Resolver reference+
21
Resolver reference-
12
Twisted pair
cables
Motor temperature sensor
25
Motor temperature sensor
24
Grounded
Optional: Inner shielding for each twisted
pair (sine, cosine, reference)
26
Cable shielding
Note:
If the motor does not support a temperature sensor, do not connect pins
12 and 25.
Hall is a single-ended signal. To use differential Hall signals, please refer to
the related wiring table.
