5.12 Parameter Details
5-111
CBM-20A/20Alite
5
5.12.6 System Controller
 Method Parameters for the System Controller
CBM-20A
The [Event Out 1 (Relay1)] to [Event Out 4 (Relay4)] fields under [Event Signals
Setting] in the system controller "Configuration Parameter" window must have [Event]
set for the output numbers used to control the relay outputs using event-output
parameters.

Sub-controller vp, Option Box vp, Option Box L, Valve Interface
Only the 4 settings from [2 Position Valve A] to [6 Position Valve D] can be used for
Sub-controller B.
Parameter
Setting
range
Default
setting
Remark
Event Output:
Event1
Event2
Event3
Event4
On, Off Off
Event output is controlled by turning the 4 (2 with
CBM-20-Alite) relay contact outputs ON and OFF.
Click the check box to enable the corresponding
event output. The selected event outputs are
displayed in gray.
Multiple Terminal
Box
On, Off On
This setting turns ON/OFF the power from the
Multiple Terminal Box outlet marked "SWITCHED".
Multiple Terminal Box cannot be used with CBM-
20Alite.
The CBM always starts up with this parameter "ON",
and the setting becomes effective after the first
action, for example pump "ON".
Parameter
Setting
range
Minimum
unit
Default
setting
Remark
2 Position Valve A
2 Position Valve B
0, 1 0
Sets the position of 2-position valves A
and B.
6 Position Valve C
6 Position Valve D
1, 2, 3,
4, 5, 6
1
Sets the position of 6-position valves C
and D.
Solenoid Valve
(FCV-10AL type)
1, 2, 3, 4 1 Sets the position of the 4-position valve.
Solenoid Valve
(FCV-11AL type)
1a, 1b/
2a, 2b/
3a, 3b
1a/2a/3a Sets position a or b for flow lines 1 to 3.
Degassing Unit
Off
Purge
Operate
Off
Used to control the online degassing
unit.
Syringe Unit
Aspiration Speed
(µL/sec)
1 to 150 1 5 Used if Sub-controller A is Option Box L.
Syringe Unit
Discharge Speed
(µL/sec)
1 to 150 1 5 Used if Sub-controller A is Option Box L.
