5. Application Operation
5-116
CBM-20A/20Alite
1. This function is not available on B.GE1 in fast LC mode.
2. For LC-30ADs earlier than version 2.10, the LP.GE mode cannot be used.
3. For LC-30ADs earlier than version 2.10, the available setting range is 0.0000 to 5.0000.
 LC-20AB
1. This function is not available in fast LC mode.
T.GE1
PASV
PBSV
PCSV
Number of FCV-10AL
type solenoid valve
1 to 4 1 1
Number of FCV-11AL
type solenoid valve
0 to 123 1 0
For example, set
[13] to turn ON
solenoid valves 1
and 3.
LP.GE1
(See note 2.)
T.FLO W
Total flow rate for
gradient pumping
(mL/min)
0 to 10.0000 0.0001 0 (See note 3.)
B.CONC
C.CONC
D.CONC
Concentration of
solvent B, C, and D
(%)
0 to 100 0.1 0
B.CURV
C.CURV
D.CURV
Gradient curve profile
of solvent B, C, and D
10 to 10 1 0
Module Function Description
Setting
range
Minimum
unit
Default
setting
Remark
Module Function Description
Setting
range
Minimum
unit
Default
setting
Remark
B.GE1 to
B.GE4
T.FLO W
Total flow rate (mL/
min) for gradient
pumping
0 to 10.0000 0.0001 0
B.CONC
Concentration of
solvent B (%)
0 to 100 0.1 0
B.CURV
(See note 1.)
Gradient curve profile
of solvent B
10 to 10 1 0
PSV
Number of FCV-10AL-
type solenoid valve
1 to 4 1 1
Number of FCV-11AL-
type solenoid valve
0 to 123 1 0
For example, set
[13] to turn ON
solenoid valves 1
and 3.
