Shimadzu CBM-20A User Manual

5.13 List of Time-program Commands
5-115
CBM-20A/20Alite
5
5.13 List of Time-program Commands
The commands that are used for all the components when creating a time program, along
with descriptions, setting ranges, and default settings, are given below.
The commands displayed in pull-down menus vary according to the configuration of
connected components.
5.13.1 Solvent Delivery Module
 LC-30AD
Module Function Description
Setting
range
Minimum
unit
Default
setting
Remark
ISO1 to ISO4
FLOW Flow rate (mL/min) 0 to 10.0000 0.0001 0 (See note 3.)
PSV
Number of FCV-10AL
type solenoid valve
1 to 4 1 1
Number of FCV-11AL
type solenoid valve
0 to 123 1 0
For example, set
[13] to turn ON
solenoid valves 1
and 3.
B.GE1, B.GE3
T.FLO W
Total flow rate for
gradient pumping
(mL/min)
0 to 10.0000 0.0001 0 (See note 3.)
B.CONC
Concentration of
solvent B (%)
0 to 100 0.1 0
B.CURV
(See note 1.)
Gradient curve profile
of solvent B
-10 to 10 1 0
PASV
PBSV
PCSV
PDSV
Number of FCV-10AL
type solenoid valve
1 to 4 1 1
Number of FCV-11AL
type solenoid valve
0 to 123 1 0
For example, set
[13] to turn ON
solenoid valves 1
and 3.
T.GE1
T.FLO W
Total flow rate for
gradient pumping
(mL/min)
0 to 10.0000 0.0001 0 (See note 3.)
B.CONC
C.CONC
Concentration of
solvent B (C) (%)
0 to 100 0.1 0
B.CURV
C.CURV
Gradient curve profile
of solvent B (C)
10 to 10 1 0
