9. Technical Information
9-6
CBM-20A/20Alite
1
Insert the connector side of the power cord into the power cord connector at the back of
the instrument.
Fig. 9.5
2
Insert the plug side of the power cord into the power supply outlet.
Grounding
WARNING
To prevent electric shock and to maintain stability in operation of the product, be sure to
ground the product.
The product will be grounded when the provided 3-wired power plug is inserted into a 3-
wired power socket equipped with a ground terminal.
Connect to power outlet
Plug side
Connector side
Power cord connector
To Next Page
