9. Technical Information
9-24
CBM-20A/20Alite
8
Set the communication mode at the Chromatopac.
C-R8A:
Set the baud rate for the STD1 port to "19200" and the communication mode to
"12917" from the "T: TRS" screen in "CONFIG".
C-R7Aplus:
Set the baud rate to "9600" with the DIP switch. Set the communication mode from
the "Communication Port Parameters" screen in Win4, as shown in the previous
table.
9
Close Internet Explorer.
10
Reset the power to the system controller and Chromatopac.
11
Digital communications is possible for the C-R8A via an optical-link cable. Enter [OPEN
GCLC 7,1,1] and press to establish digital communications between the system
controller and the C-R8A.
Remote operation of the system controller from the C-R7A Chromatopac becomes
possible by entering [OPEN TRS 7] from Chromatopac keyboard and press .
The communication port should be closed before turning OFF the power to the
system controller or Chromatopac. If it was opened using [OPEN GCLC 7,1,1],
enter [CLOSE GCLC 1] and press . If it was opened using [OPEN TRS
7], enter [CLOSE TRS 7] and press .
