9. Technical Information
9-30
CBM-20A/20Alite
1
Turn the system controller power ON while pressing the initialization button and
continue to hold the initialization in the pressed position for approximately 20 seconds.
When initialization is complete, the 100M, ACT, and LINK indicators on the back of the
system controller all turn ON briefly and then turn OFF and return to the normal status
The status indicator of the CBM-20A changes from orange to green.
9.3.2 Making TCP/IP-related Settings
The [IP address], [Subnet mask], [Default gateway], and [Ether speed] parameters can be set
via the CBM-20A's RS-232C terminals.
1
Connect the RS-232C terminals on the CBM and the RS-232C terminals on the PC
with a crossover cable.
Use one of the recommended cables given in 1.3 Optional Parts or a commercial 9pin
Dsub-9pin Dsub cable.
2
Start the terminal software, such as Hyper Terminal, at the PC.
Configure the following settings with terminal software:
Bits per second: 9600
Data bits: 8
Parity: None
Stop bits: 1
Flow control: None
Reset the power to the system controller while pushing the initialization button.
When the message [Release INIT-SW to enter boot menu or initialize all parameter] is
displayed on the terminal, release the button.
If approximately 5 seconds elapse after startup and the message is not displayed on
the terminal, release the initialization button and examine the terminal settings and
cable connections. If the button remains in the pressed position, the entire system will
be initialized.
3
When the following message is displayed on the terminal, press the [Enter] key.
CBM-20A Loader version X.XX
Press the [Enter] key to proceed:
The current settings are displayed on the terminal.
1. IP address : 192.168.200.99
2. Subnet mask : 255.255.255.0
3. Default gateway :
4. Ether speed : 0 (Auto)
5. Boot parameter :
v. ROM Version Up from serial port
1-5: Change or 0 : quit ?
To Next Page
